LOGSET 12H GTE HYBRID HARVESTER

The Logset 12H GTE 510 hp Hybrid Harvester caused quite a stir at the APF Show in 2016. Once the show was done and dusted it made the long journey to Aberfoyle in Stirlingshire. John and Sue Fukes of R.J. Fukes Forestry Services and Marc Mimeau from Logset arranged a demonstration of the harvester at a steep Tillhill site managed by Richard Rattray on the Forestry Commission’s three lochs forest drive. It was a fairly mixed size crop of Sitka Spruce, with some of the timber over two cubic metres in volume and steep clicks up to an old clear fell site at the top (which I harvested alongside Aaron Ferguson a few years ago).

The harvester was almost 28,000 kg in weight once it was completely tracked up with Clark Climbing Specials (24,500kg without); it’s powered by a Tier 4 Final 300hp diesel motor with up to 210hp of hybrid power on tap when necessary. This is a very clever system which provides incredible power but is also environmentally friendly with efficient fuel consumption and low emissions.

We arrived on the Friday afternoon and the first day of the demonstration was well underway with Ian Pattison at the controls, being watched by a lot of people who had travelled a fair distance to see this big beast in action. The climbing ability of the harvester was especially impressive considering it was on standard bogies with

hydraulic rams; this unit is destined for flat ground in Finland but balanced bogies will be an option on future hybrids. The stability of the harvester was outstanding, even when felling trees at the full reach of the Mesera 280V Crane.

Graham Miller, a harvester driver for the Forestry Commission, took a



Logset 12H GTE Hybrid Harvester - Aberfoyle Demo 2016

Marc Mimeau at Interforst 2018

test drive with Ian Pattison to see how it compared to the John Deere he normally operates and this is what he had to say: “Overall it’s quite an impressive machine. The climbing ability is very good; the slope I was on was measured at just over 32 degrees. Also the stability is very good, working with large trees on the slope it never moved. The cab has great vision, with the glass sides and the windscreen going right to the floor. From a maintenance point of view the head looks easy to work on and although I think the JD 415 head is faster at feeding it can still handle a fair size stick. Ian said there are a few things that need tweaking on it so it will be interesting to see how it goes once this has been done.”

Over the two days the Logset Hybrid worked a total of 12 hours and cut a total of just over 600m³, which is an average of 50m³/hr. The average fuel consumption was 14ltr/hr.

Overall, I thought it was a solid, well built and effective machine; some pipes on the bogie rams were vulnerable but John Fukes already had this noted and a solution worked out in advance. The hybrid was well received by the people attending over the two days and most were very impressed with the climbing ability and stability; the only negative comment I heard was that the feeding speed of the TH75

harvesting head was slower compared to some of their leading competitors.

It was also reasonably quiet for such a powerful machine and although it was grossing at almost 28,000kg there was minimal evidence of damage to the forest floor. Although it appears to be a really big machine, it is transported with a normal low loader from site to site with ease. I am sure most other manufacturers will follow suit at some point with the hybrid system but Logset have written themselves into the history books by being the first.


I caught up with Marc Mimeau, the area sales manager for Logset at Interforst 2018 to find out how the Hybrid was being received two years after its launch.

Marc was delighted with its progress said that this was the sixth Hybrid that had been manufactured and sold with a further two currently in production.

I noticed some sign writing on the side of the Hybrid and asked if this was the new owners but Marc explained that the “Bayerische Staatforsten” (BAYSF) logo was in fact the Bavarian State forest management company.

The BAYSF is responsible for the management of 800,000ha of forests in Bavaria and Sankt Martin bei Lofer in the Austrian state of Salzburg.

It is the largest management company in Germany and was formed in 2005 It is focused on preserving the forests and

eco-systems under its control by utilising a sustainable strategy with a strong focus on social responsibilities. The BAYSF harvests five million cubic meters each year (10% of all the timber harvested in Germany) and keeps over 2,600 people employed.

Having the BAYSF logo on the Hybrid is very prestigious as it means that it complies to all the high standards laid down by them and that they endorse the Hybrid as an efficient and

environmentally friendly machine for harvesting timber.

This endorsement can have a big impact on the sales of a machine in Germany and beyond as BAYSF is a highly respected organisation in the forest community.

Marc was overwhelmed with the attention, positive feedback and enquiries Logset received from the visitors at Interforst.

You never know there might be a Logset 12H GTE Hybrid coming to a forest near you.
